Methodology
Our methodology for soil mechanics laboratory in Wigan begins with a thorough desk study of geological maps and historical records, followed by a site walkover. We then deploy a tailored investigation programme, typically including soil mechanics laboratory boreholes with SPT testing per BS 1377-9, trial pits, and geophysical surveys where needed. Sampling intervals and test types are chosen based on the anticipated ground model. All fieldwork is supervised by a chartered engineer, and laboratory testing follows UKAS-accredited procedures. The resulting data is interpreted to provide design parameters for foundations, slope stability, and earthworks, with full traceability and quality assurance.
Reference Technical Parameters
| Parameter | Reference Value |
|---|---|
| Predominant soil type | Glacial till (boulder clay) over Coal Measures mudstone/sandstone |
| Maximum seismic acceleration (PGA) | 0.05g (low seismicity per BS EN 1998-1) |
| Typical groundwater level | 2–5 m below ground surface, variable with season |
| Bedrock depth | 10–30 m in valley areas; shallow (<5 m) on higher ground |
| Typical N60 range (SPT) | 15–30 in till; 8–15 in alluvium; 50+ in bedrock |
Local Considerations — Wigan
Wigan's geology is dominated by glacial till overlying Carboniferous Coal Measures, with superficial alluvial deposits along the River Douglas and its tributaries. The till is typically stiff to very stiff, but can contain sand and gravel lenses that affect drainage and bearing capacity. Groundwater levels are generally shallow in low-lying areas, requiring careful dewatering considerations. The region is classified as low seismicity per BS EN 1998-1, with PGA values around 0.05g. Infilled mining shafts and shallow coal workings are a legacy hazard in parts of the borough, demanding thorough historical research. For projects requiring specialized support, our soil mechanics laboratory en Manchester provides additional capacity and expertise for complex investigations.
Request a Quote
Our team reviews your project and issues an initial report at no cost.
Or write us directly at [email protected]
Services in Wigan
Applicable Standards
- BS 5930 (Code of Practice for Ground Investigations)
- BS 1377-9 (Methods of Test for Soils for Civil Engineering Purposes)
- Eurocode 7 (BS EN 1997-1 and 1997-2)
- BS EN 1998-1 (Eurocode 8: Seismic Design)
Frequently Asked Questions
What are the typical soil conditions for foundations in Wigan?
Most of Wigan is underlain by stiff glacial till, which provides good bearing capacity for shallow foundations. However, alluvial deposits in valley bottoms and made ground in former industrial areas can be problematic, often requiring deeper foundations or ground improvement. A site-specific investigation is essential.
Is seismic design required for structures in Wigan?
Wigan falls within the low seismicity zone of the UK, with a peak ground acceleration of approximately 0.05g. Eurocode 8 does not mandate seismic design for ordinary structures in this zone, but certain critical infrastructure or large-span buildings may still require consideration. Our team can advise on the specific requirements for your project.
Are geotechnical investigations mandatory for building projects in Wigan?
While not always a legal requirement for small domestic extensions, a ground investigation is strongly recommended for any structure to confirm design assumptions and avoid costly failures. For larger developments, local planning authorities typically require a geotechnical report as part of the planning application, especially in areas with known mining legacy or variable ground conditions.
