Methodology
Our methodology for projects in Bournemouth follows a systematic approach tailored to local geology. We begin with a desk study reviewing existing boreholes and geological maps, then plan field investigations using methods such as soil mechanics laboratory techniques including SPT (ASTM D1586) and dynamic sampling. Sample intervals are typically 1.0–1.5 m, reaching depths of 8–15 m for residential structures. Laboratory tests on retrieved samples include classification, strength, and consolidation properties. Data analysis considers settlement, bearing capacity, and groundwater effects, with final reports providing design parameters. This rigorous process ensures compliance with standards like Eurocode 7 and BS 5930.
Reference Technical Parameters
| Parameter | Reference Value |
|---|---|
| Predominant soil type | Sands and gravels over clay |
| Typical N60 range (SPT) | 10–30 blows/ft in sands |
| Groundwater depth | 2–5 m below ground level |
| Peak ground acceleration (PGA) | 0.12g (BS EN 1998-1) |
| Bedrock depth | >30 m (variable) |
Local Considerations — Bournemouth
Bournemouth's geology is dominated by Quaternary deposits: river terrace sands and gravels overlying London Clay and Bagshot Beds. Groundwater is often shallow (2–5 m), requiring dewatering or waterproofing in basements. Seismic hazard is low (PGA ~0.12g) per BS EN 1998-1, but liquefaction potential in loose sands warrants assessment. Older Victorian buildings may have shallow foundations needing underpinning. For regional context, our soil mechanics laboratory en Bristol provides similar expertise in the South West.
Request a Quote
Our team reviews your project and issues an initial report at no cost.
Or write us directly at [email protected]
Services in Bournemouth
Applicable Standards
- ASTM D1586 (Standard Penetration Test)
- BS 5930 (Code of practice for site investigations)
- Eurocode 7 (Geotechnical design)
- BS EN 1998-1 (Seismic design)
- NHBC Standards (for residential projects)
Frequently Asked Questions
What are the typical soil types encountered in Bournemouth?
Bournemouth's soils are predominantly river terrace sands and gravels overlying London Clay and Bagshot Beds. These layers can vary laterally, requiring careful investigation to assess bearing capacity and settlement behavior.
Is seismic design required for structures in Bournemouth?
According to Eurocode 8 (BS EN 1998-1), Bournemouth is in a low seismicity zone with a PGA of 0.12g. While seismic design is typically not critical, it may be considered for essential buildings or loose sandy soils prone to liquefaction.
How deep should a site investigation be for a typical residential project in Bournemouth?
For most residential buildings, boreholes to depths of 8–15 m are sufficient to characterize the soil profile and groundwater conditions. The depth depends on foundation type and load, with deeper investigations for pile foundations.
